The VX2000 Pro is an all-in-one controller combining video processing and video control functionalities into a single device. Equipped with 20 Ethernet ports, it supports three working modes: video controller, fiber converter, and ByPass. Capable of managing up to 13 million pixels, the VX2000 Pro can output at a maximum width of 16,384 pixels and a height of 8,192 pixels, making it perfectly suited for controlling ultra-wide and ultra-high LED screens on-site.
The VX2000 Pro boasts powerful video signal reception and processing capabilities, supporting a maximum resolution of 4K×2K@60Hz for video input. It can handle multiple video signal inputs and includes features like 12 layers, output scaling, low latency and pixel-level brightness and chroma calibration. These functions combine to deliver outstanding image display quality.
With various control options available, the VX2000 Pro can be operated via the front panel knob, NovaLCT, Unico web page and VICP app, providing you with a convenient and effortless control experience.
The VX2000 Pro is housed in an industrial-grade casing, which, combined with its powerful video processing and transmission capabilities, makes it robust and well-suited for complex operational environments. The VX2000 Pro is a perfect fit for medium and high-end rental, stage control systems and fine-pitch LED screens.
BUILT-IN SCALING (AUTO FIT CONTENT TO WALL): YES
INPUTS: 10 - DP1.2 (1x), HDMI 2.0 (2x), HDMI 1.3 (4x), 12G-SDI (1x), USB (1x), Opt 1
OUTPUTS: LED OUTPUTS - 20
GENLOCK: YES
IMAGE MOSAIC (MULT. PROCESSORS ON 1 WALL): YES
VIDEO LOOP: YES
MONITOR: HDMI
BUILT IN FIBER SLOTS: YES
WINDOWS/LAYERS: 12 (2k x 1k)
3D: YES (Supports 3D Effect. Output capacity is cut in half when 3D is enabled)
CONTROL:
ETHERNET ( Webpage Control via Network) / USB Type B (PC Control)
LOADING CAPACITY:
MAX PIXELS PER LED OUTPUT: 650,000 pixels (at 8-bit)
TOTAL PIXELS: 13 million pixels
MAXIMUM INPUT RESOLUTION: 4096 x 2160 @ 60Hz (When using HDMI 2.0 or DP 1.2 Input)
MAX OUTPUT WIDTH/HEIGHT: 16384 pixels x 8192 pixels (W x H or H x W)
