BUILT-IN SCALING (AUTO FIT CONTENT TO WALL): YES
INPUTS: 8
- DP 1.2 (4K capable)
- HDMI 2.0 (4K capable)
- (2x) 12G SDI (both are 4K capable)
- (4x) DVI (4 single-link DVI or 2 dual-link DVI....Dual-link 1 & 3 are 4Kx1K = 4K together)
OUTPUTS: LED OUTPUTS: 16
GENLOCK: YES (IN, LOOP)
IMAGE MOSAIC (MULT. PROCESSORS ON 1 WALL): YES (VIDEO LOOP, ENGAGE SCALING)
VIDEO LOOP: HDMI LOOP, SDI LOOP (2x)
MONITOR: HDMI
BUILT IN FIBER SLOTS: YES - OPT1 (1-8), OPT2 (9-16), 2 BACKUP (for use with CVT4K-S)
WINDOWS/LAYERS: 2 (via PIP)
CONTROL:
ETHERNET (For communicating via network) / USB Type B (PC Control) /
USB Type A (Cascading Multiple Devices) / RS232
LOADING CAPACITY:
MAX PIXELS PER LED OUTPUT: 650,000 pixels
TOTAL PIXELS: 10.4 million pixels
MAXIMUM INPUT RESOLUTION: 4096 x 2160 @ 60Hz
MAX OUTPUT WIDTH/HEIGHT: 16384 pixels x 600 pixels (W x H)
8192 pixels x 1260 pixels (H x W)
MINIMNUM OUTPUT WIDTH/HEIGHT: 800 pixels x 600 pixels
