The MX6000 Pro is a professional 8K LED display controller from NovaStar, designed as part of the COEX control system series. Its remarkable features include 12-bit color depth, 360 Hz capability, real-time multi-screen scaling, 0-frame latency, and HDR supportability providing precise brightness control, true-to-life color fidelity, and an excellent image quality. Its card-based modular design is specifically tailored for future LED displays allowing for flexible input and output card configurations that are stable and easy to maintain. With a compact 6U size, it supports up to 32x 4K or 8x 8K video inputs with a maximum load capacity of 141 million pixels making it ideal for large-screen configurations.
The MX6000 Pro offers a wide range of options with up to seven different input cards supporting 8K, 4K, and VoIP. For output, it supports two types of output cards: 4x 10G fiber and 1x 40G fiber. These cards can be configured flexibly to accommodate either 1G or 5G bandwidth for the control system, catering to different requirements. Additionally, it supports seamless backup and automatic switching between devices, cards, and Ethernet ports. In case of any malfunction it promptly switches over while issuing automatic alerts ensuring stable output on-site. To further enhance the user experience it is complemented by the advanced control software, VMP, enabling users to have better control and management capabilities.
The MX6000 includes features such as:
Genlock, Image Scaling, 14CH Color Correction, Color Replacement, Full Greyscale Calibration, Dynamic Booster, Low Latency (1 frame in All-In-One Controller working mode), Frame Rate Adaptive, Frame Multiplication, 3D, Shutter Fit
The Frame Rate Adaptive function only works with the A10s Pro receiving card. Currently supported driver ICs include ICND2055, ICND2065, ICND2069, ICND2076, MBI5264, MBI5264B, and MBI5264C. In addition, the .ncp file generated by the Cabinet Tool from NovaStar must be used.
- The Dynamic Booster function only works with the A10s PRO receiving card
The Full Grayscale Calibration function only works with the A10s Pro, CA50e, CA50c, or XA50 receiving cards and users need to use a C3200 camera to perform the full-grayscale calibration.
Low latency not available when Genlock is used.
The MX6000 input and output cards are sold separately. There are a few to choose from (click on the card name to go to that product and add to your cart):
- Input Card: MX_4xHDMI 2.0 Input Card (4K)
- Input Card: MX_2xHDMI 2.1 Input Card (8k)
- Input Card: MX_2xDP 1.4 Input Card (8K)
- Input Card: MX_4x DP 1.2 Input Card (4K)
- Input Card: MX_4x 12G-SDI Input Card (4K)
- Output Card: MX_4x10G Fiber Output Card
- Output Card: MX_1x 40G Fiber Output Card (Coming Soon)
BUILT-IN SCALING (AUTO FIT CONTENT TO WALL): Yes
INPUTS: 4k: 4x HDMI 2.0, 4x DP1.2, 4x 12G-SDI
8k: 2x HDMI 2.1, 2x DP 1.4
OUTPUTS: Up to 32x 10G Fiber Output ports (Each 10G OPT port is equal to 10x 1G ethernet ports)
Up to 8x 40G Fiber Output ports (Each 40G OPT port is equal to 8x 5G ethernet ports)
BUILT IN FIBER SLOTS: YES - Up to 21x 10G OPT Ports or 8x 40G OPT Ports
LOADING CAPACITY: MAX PIXELS PER OPT OUTPUT:
10G OPT Ports = 6,550,000 pixels (8-bit @ 60Hz)
40G OPT Ports = 20,736,000 pixels (8-bit @ 60Hz)
TOTAL PIXELS: 141 million pixels (8-bit @ 60Hz)
MAXIMUM INPUT RESOLUTION: 7680 x 4320 @ 30Hz (using 8k Input)
MAX OUTPUT WIDTH/HEIGHT: 8192 pixels x 8192 pixels (W x H or H x W)
