NovaStar VX16S All-in-One Controller (LED Video Processor + Scaling)
NovaStar VX16S All-in-One Controller (LED Video Processor + Scaling)

NovaStar VX16S All-in-One Controller (LED Video Processor + Scaling)

Brand: NovaStar

Regular price $2,929.00 On Sale

  • This product is temporarily out of stock. Please contact us for an ETA.

    Pricing shown above is MAP pricing before the international tariff/handling fee (added at checkout).



     Click the image above to see a NovaStar VX16S overview video



    BUILT-IN SCALING (AUTO FIT CONTENT TO WALL): YES

    INPUTS: 7 - HDMI 2.0 (1x), SL-DVI (4x), 3G-SDI (2x)

    OUTPUTS: LED OUTPUTS - 16

    GENLOCK: NO

    IMAGE MOSAIC (MULT. PROCESSORS ON 1 WALL): YES

    VIDEO LOOP: NO

    MONITOR: HDMI

    BUILT IN FIBER SLOTS: NO

    WINDOWS/LAYERS: 3 (via Main Layer, PIP 1, PIP 2)

    3D: YES (Supports 3D Effect. Output capacity is cut in half when 3D is enabled)

    CONTROL:

    ETHERNET (For communicating via network) / USB Type B (PC Control)

    RS232 (For 3rd party control)

    USB Type A (Cascading Multiple Devices)

    LOADING CAPACITY:

    MAX PIXELS PER LED OUTPUT: 650,000 pixels

    TOTAL PIXELS: 10.4 million pixels

    MAXIMUM INPUT RESOLUTION: 3840 x 2160 @ 60Hz (When using HDMI Input)

    MAX OUTPUT WIDTH/HEIGHT: 16384 pixels x 8192 pixels (W x H or H x W)

    VX16S SPEC SHEET

    OFFICIAL VX16S USER MANUAL
